Technical requirements for nitrogen generators in various fields
2024/1/31
Application field:
Oil and gas loading and unloading,explosion-proof protection,maintenance and blowing of oil and gas pipelines such as oil depots,gas depots,and oil port terminals;
Oxygen isolation protection,fire prevention,material transportation,and pipeline blowing in chemical production processes;
Oil well survey,oil and gas extraction,well completion maintenance services,tertiary oil recovery and nitrogen injection in the oilfield,to increase oil and gas production.
Nitrogen production:5-2000Nm³/H(under standard conditions)
Nitrogen purity:95.0%~99.999%(national standard non oxygen content)
Nitrogen pressure:0.01~0.8Mpa(gauge pressure,stable and adjustable)(can reach 35Mpa after boosting)
Nitrogen dew point:-40℃~-69℃(atmospheric dew point)
Nitrogen supply requirements:large gas consumption and high pressure;Some processes require low levels of impurities such as CO,CO2,and H2O in nitrogen.Special environments require the use of explosion-proof nitrogen generators,mobile nitrogen generators,and all stainless steel nitrogen generators.For outdoor use,on-site power generation or diesel air compressors are required.
Application field:
The production of high-voltage cross-linked cables and high-quality cables.
Nitrogen production:10-2000Nm³/H(under standard conditions)
Nitrogen purity:99%~99.99%(national standard non oxygen content)
Nitrogen pressure:0.01~0.8Mpa(gauge pressure,stable and adjustable)(pressurized to 2.5Mpa through a fully oil-free booster)
Nitrogen dew point:-40℃~-45℃(atmospheric dew point)
Nitrogen supply requirements:According to the national industry standards for cables,nitrogen must be used as a protective gas during the production of 35KV and above cross-linked cable production lines to prevent oxidation and combustion of cross-linked polyethylene at high temperatures.The purity of nitrogen is generally 99.5%(with an oxygen content of 0.5%),and the pressure of nitrogen usage is 0.8 to 1.6 MPa.Generally,the nitrogen consumption for the production of a single suspension chain and tower line in China is 6-20 Nm³/Hr,the nitrogen consumption for the production of imported suspension chains and tower lines is 40-60Nm³/Hr,the specific nitrogen consumption should be determined based on whether there is a rotary chamber,whether it is water-cooled or air-cooled,the interval and time setting for exhaust gas emission,etc.
Application field:
Wave soldering,lead-free reflow soldering,soldering,packaging and blowing,sealing of high-precision chips,and firing of bases;
Production of SMT,piezoelectric crystals,integrated chips,and integrated circuits.
Nitrogen production:5-1000Nm³/H(under standard conditions)
Nitrogen purity:99.9%~99.9995%(national standard non oxygen content)
Nitrogen pressure:0.01~0.8Mpa(gauge pressure,stable and adjustable)
Nitrogen dew point:-40℃~-69℃(atmospheric dew point)
Nitrogen cleanliness:particle size≤0.01μm.Oil content≤0.01ppm W/W
Nitrogen supply requirements:High purity and low dew point of nitrogen are required,and the product nitrogen does not contain impurities such as H2,CO,CO2 dust,or has a low content.
Application field:
Nitrogen protection,nitrogen sealing,pipeline blowing,material transportation and distribution in pharmaceutical and chemical production;
Prevent oxidation and combustion failure of raw materials,as well as pollution of raw materials and finished products;
In biopharmaceuticals,it prevents oxidation,inhibits bacterial growth,produces odors,and protects the entire process;
Grain storage in grain depots is resistant to spontaneous combustion,insects,and mold.Oil storage,filling and nitrogen sealing.
Nitrogen production:5-1000Nm³/H(under standard conditions)
Nitrogen purity:99.0%~99.999%(national standard non oxygen content)
Nitrogen pressure:0.01~0.8Mpa(gauge pressure,stable and adjustable)
Nitrogen dew point:-40℃~-69℃(atmospheric dew point)
Nitrogen cleanliness:particle size≤0.01μm.Oil content≤0.01ppm W/W,(for sterilization and odor removal)
Nitrogen supply requirements:High equipment configuration,some processes require all stainless steel nitrogen making machines;High purity and low dew point requirements for nitrogen;High requirements for nitrogen cleanliness,dust-free,sterile,and odorless;It is required that the impurities such as CO,CO2,H2O,and CmHn in nitrogen should be very low,meet the pharmaceutical and health standards for drug production,and the equipment should meet GMP certification requirements.
Application field:
Steel annealing,quenching,carburizing,carbonitriding,soft nitriding and other nitrogen based atmosphere heat treatment;
Metal powder metallurgy sintering and oxygen isolation protection;
Metal smelting and forming,sealing of blast furnace top,and injection of coal powder for blast furnace ironmaking;
Atmosphere protection for heat treatment of new materials and composite material hot press tanks.
Nitrogen production:5-2000Nm³/H(under standard conditions)
Nitrogen purity:98.0%~99.999%(national standard non oxygen content)
Nitrogen pressure:0.01~0.8Mpa(gauge pressure,stable and adjustable)
Nitrogen dew point:-45℃~-69℃(atmospheric dew point)
Nitrogen supply requirements:Nitrogen has high purity,low dew point,and sometimes requires a large instantaneous amount;Sometimes a mixture of N2 and H2 is required for use.
Application field:
Laser cutting machine nitrogen protection,radial tire production tire vulcanization nitrogen filling protection.
Nitrogen production:10-1000Nm³/H(standard condition)
Nitrogen purity:99.99%~99.999%(national standard non oxygen content)
Nitrogen pressure:1.6~4.2Mpa(gauge pressure,stable and adjustable)
Nitrogen dew point:-45℃~-69℃(atmospheric dew point)
Nitrogen supply requirements:high nitrogen purity,low dew point,high nitrogen pressure,and stable gas supply.
Application field:
Liquefied natural gas storage and transportation,production of new materials for lithium-ion batteries,production of new materials for polycrystalline silicon solar energy,explosion-proof coal powder silos,and flame retardant brown coal.
Nitrogen production:5-1000Nm³/H(under standard conditions)
Nitrogen purity:95.0%~99.999%(national standard non oxygen content)
Nitrogen pressure:0.01~0.8Mpa(gauge pressure,stable and adjustable)
Nitrogen dew point:-45℃~-69℃(atmospheric dew point)
Nitrogen cleanliness:particle size≤0.01μm.Oil content≤0.01ppm W/W
Nitrogen supply requirements:With the development and utilization of new energy,the requirements for energy conservation and environmental protection are becoming increasingly high.Require high nitrogen purity,low dew point,and high nitrogen cleanliness;Continuous use of nitrogen ensures good stability.
